DC24V Power
Multiple connector options for quick, fexible installation
High reliability, long lifespan, ultra-low noise
Multiple performance confgurations available
PWM을 지원합니다, RS485, CAN communication
Compatible with deionized water, coolant, glycol fuorinated fuids, 실리콘 오일
| Product Name | Electronic Water Pump |
|---|---|
| Model | CG0224252501 |
| Product weight | 500g |
| Lifetime | ≥15000 hours |
| Rated voltage | 24V DC |
| Working voltage range | 12-30다섯 (Pump works fine in this range) |
| Rated current | 3.6±10% A (@max flow rate) |
| Input power | 88W (@max flow rate) |
| Maximum flow | 25±15%L/min (Maximum flow the pump can achieve at rated voltage) |
| Maximum head | 25±2m (Maximum head the pump can achieve at rated voltage) |
| Maximum input current | 4.5A (When overloaded) |
| Protection rating | IP67 |
| Color | Black |
| Environtemal protection level | Comply with Rohs |
| Frame material | PPA |
| 소음 | ≤40dBA(at a distance of 1 meter from the pump, the background noise is ≤20dBA) |
| Insulation class | Class F(155℃） |
| Working principle | Centrifugal pump |
