AC220V Power
High reliability, long lifespan
Optional quick-connect fittings
PWM을 지원합니다, RS485, CAN communication
Wide temperature range: -40'C to 125°C
Suitable for deionized water, coolant, glycol solutions
AC220V Power
High reliability, long lifespan
Optional quick-connect fittings
PWM을 지원합니다, RS485, CAN communication
Wide temperature range: -40'C to 125°C
Suitable for deionized water, coolant, glycol solutions
| Product Name | Electronic Water Pump |
|---|---|
| Model | CJ0622458028 |
| Product weight | 3kg |
| Lifetime | ≥15000 hours |
| Rated voltage | 220V AC |
| Working voltage range | 180-260V AC (Pump works fine in this range) |
| Input power | 400±10% W (@max flow rate) |
| Maximum flow | 80±15%L/min (Maximum flow the pump can achieve at rated voltage) |
| Maximum head | 45±3m (Maximum head the pump can achieve at rated voltage) |
| Color | Black |
| Environtemal protection level | Comply with Rohs |
| Frame material | PPA/PA66 |
| 소음 | ≤60dBA(at a distance of 1 meter from the pump, the background noise is ≤20dBA) |
| Protection level | IPX4 |
| Insulation class | Class F(155℃） |
| Working principle | Centrifugal pump |
