| Parameter | Value | Unit |
|---|---|---|
| Dimensions | 120*120*25mm | |
| Bearing type | HDB bearing | |
| Speed | 600-2000 RPM±10% | RPM |
| Maximum airflow | 58.3 CFM | CFM |
| Maximum static pressure | 2.25 H2O | mmH2O |
| Noise | 25 dBA | dBA |
| Rated voltage | 12V | V |
| Rated current | 0.25A | A |
| Power consumption | 2-4w | W |
| Expected life | 30000 HRS/25°C | hours |
| Connector | 4PIN PWM | |
| Cable length | 41cm | |
| Material | PBT |
