HR8060H12B DC Brushless Blower 80×60mm B Type
| Parameter | Value | Unit |
|---|---|---|
| Dimensions | 80×60mm | mm |
| Type | B Type | |
| Rated voltage | 12 | V |
| Operating voltage | 10~16 | V |
| Rated current | 11.4 | |
| Rated input power | 136.8 | W |
| Speed | 43000 | RPM |
| Maximum airflow | 28.6 | CFM |
| Maximum static pressure | 1250.3 | mmH2O |
| Noise | 72.4 | dBA |
| Application | Vacuum system、Air cushion machine 、Seafood transporter | |
| Bearing | Ball / configurable bearing code per our catalog | |
| Frame | Aluminum (Flammability:UL94V-0) | |
| Impeller | Aluminum (Flammability:UL94V-0) |
